Power output: 2x85 watts continuous into 8 ohms.
The output stage topology is quasi-complementary employing NPN transistors only.
The amplifier uses two tubes in the input differential stage of the line amplifier.
For the vinyl enthusiasts a MM phono module is available which can be plugged in as an optional extra.
The phono module is composed by discrete components using low-noise input FET-transistors.
System remote-control: Copland RC102
Specifications:
Vacuum tubes: 2 x 6922
Rated power: 85W / channel at 8 ohms
THD: less than 0,05 % at all levels
Power bandwidth: 20 Hz - 20 kHz 0,2 dB
Frequency response: 10 Hz 100 kHz 0,5 dB
Input sensitivity:
Line: 230 mV for rated power
Phono: 2,7mV (optional extra)
Input impedance:
Line: 39 K ohms
Phono: 47 K ohms (optional extra)
S/N ratio: ( IHF-A curve ) More than 95 dB
Power consumption: 400 W
Nominal mains voltage: 115V or 230V factory set for destination country only
Mains voltage range: +/- 12 %
Dimensions (mm.) 430 (W) 110 (H) 390 (D)
Shipping weight : 15 kg
